Balanset-1A: State-of-the-art Mobile Balancer & Vibration Analyzer
Next-generation Dynamic Balancing Solution
Balanset-1A represents an revolutionary solution for rotor balancing of rotors in their own bearings, developed by Estonian company Vibromera OU. The device delivers professional equipment balancing at €1,751, which is significantly cheaper than traditional vibration analyzers while maintaining exceptional measurement accuracy. The system enables on-site balancing directly at the equipment’s working position without requiring removal, which is essential for reducing production downtime.
About the Manufacturer
Vibromera OU is an Estonian company specializing in the design and manufacturing of instruments for technical diagnostics of industrial equipment. The company is incorporated in Estonia (registration number 14317077) and has offices in Portugal.
Contact Information:
Official website: https://vibromera.eu/shop/2/
Technical Specifications
Detection Parameters
Balanset-1A provides precise measurements using a two-channel vibration analysis system. The device measures RMS vibration velocity in the range of 0-80 mm/s with an accuracy of ±(0.1 + 0.1?Vi) mm/s. The working frequency range is 5-550 Hz with potential extension to 1000 Hz. The system supports rotation frequency measurement from 250 to 90,000 RPM with phase angle determination accuracy of ±1 degree.
Operating Principle
The device employs phase-sensitive vibration measurement technology with MEMS accelerometers ADXL335 and laser tachometry. Two single-axis accelerometers measure mechanical oscillations proportional to acceleration, while a laser tachometer generates impulse signals for computing RPM and phase angle. Digital signal processing includes FFT analysis for frequency analysis and proprietary algorithms for automatic calculation of correction masses.
Full Kit Contents
The standard Balanset-1A delivery includes:
Measurement unit with USB interface – central module with integrated preamplifiers, integrators, and ADC
2 vibration sensors (accelerometers) with 4m cables (optionally 10m)
Optical sensor (laser tachometer) with 50-500mm measuring distance
Magnetic stand for sensor mounting
Electronic scales for accurate measurement of corrective masses
Software for Windows 7-11 (32/64-bit)
Plastic transport case
Complete set of cables and documentation
Functional Capabilities
Vibrometer Mode
Balanset-1A works as a complete vibration analyzer with abilities for measuring overall vibration level, FFT spectrum analysis up to 1000 Hz, measuring amplitude and phase of the fundamental frequency (1x), and continuous data recording. The system provides visualization of time signals and spectral analysis for equipment condition diagnostics.
Balancing Mode
The device supports single-plane (static) and two-plane (dynamic) balancing with automatic calculation of correction masses and their installation angles. The unique influence coefficient saving function permits considerable acceleration of repeat balancing of same-type equipment. A dedicated grinding wheel balancing mode uses the three-correction-weight method.
Software
The user-friendly program interface provides step-by-step guidance through the balancing process, making the device accessible to personnel without special training. Key functions include:
Automatic tolerance calculation per ISO 1940
Polar diagrams for imbalance visualization
Result archiving with report generation capability
Metric and imperial system support
Multilingual interface (English, German, French, Polish, Russian)
Usage Domains and Equipment Types
Industrial Equipment
Balanset-1A is effectively employed for balancing fans (centrifugal, axial), pumps (hydraulic, centrifugal), turbines (steam, gas), centrifuges, compressors, and electric motors. In manufacturing facilities, the device is used for balancing grinding wheels, machine spindles, and drive shafts.
Agricultural Machinery
The device offers particular value for agriculture, where reliable operation during season is essential. Balanset-1A is employed for balancing combine threshing drums, shredders, mulchers, mowers, and augers. The possibility to balance on-site without equipment disassembly permits avoiding costly downtime during busy harvest periods.
Specialized Equipment
The device is effectively used for balancing crushers of various types, turbochargers, drone propellers, and other high-speed equipment. The RPM frequency range from 250 to 90,000 RPM covers practically all types of industrial equipment.
Superiority Over Competitors
Economic Value
At a price of €1,751, Balanset-1A delivers the functionality of devices costing €10,000-25,000. The investment recovers costs after preventing just 2-3 bearing failures. Cost reduction on third-party balancing specialist services amounts to thousands of euros annually.
Ease of Use
Unlike complex vibration analyzers requiring months of training, mastering Balanset-1A takes 3-4 hours. The step-by-step guide in the software permits professional balancing by personnel without specific vibration diagnostics training.
Mobility and Independence
The complete kit weighs only 4 kg, with power supplied through the laptop’s USB port. This permits balancing in field conditions, at isolated sites, and in difficult-access locations without external power supply.
Versatile Application
One device is suitable for balancing the widest spectrum of equipment – from small electric motors to large industrial fans and turbines. Support for single and dual-plane balancing covers all common tasks.
Real Application Results
Drone Propeller Balancing
A user achieved vibration reduction from 0.74 mm/s to 0.014 mm/s – a 50-fold improvement. This demonstrates the remarkable accuracy of the device even on small rotors.
Shopping Center Ventilation Systems
Engineers successfully balanced radial fans, achieving lower energy consumption, removed excessive noise, and extended equipment lifespan. Energy savings recovered the device cost within several months.
Agricultural Equipment
Farmers note that Balanset-1A has become an indispensable tool preventing costly breakdowns during peak season. Reduced vibration of threshing drums led to reduced fuel consumption and bearing wear.
Cost and Delivery Terms
Current Prices
Complete Balanset-1A Kit: €1,751
OEM Kit (without case, stand, and scales): €1,561
Special Offer: €50 discount for newsletter subscribers
Bulk Discounts: up to 15% for orders of 4+ units
Acquisition Options
Official Website: vibromera.eu (recommended)
eBay: verified sellers with 100% rating
Industrial Distributors: through B2B channels
Payment and Shipping Terms
Payment Methods: PayPal, credit cards, bank transfer
Shipping: 10-20 business days by international mail
Shipping Cost: from $10 (economy) to $95 (express)
Warranty: factory warranty
Technical Support: included in price
Conclusion
Balanset-1A stands as an optimal solution for organizations striving to implement an efficient equipment balancing system without significant capital expenditure. The device makes accessible access to professional balancing, enabling small enterprises and service centers to offer services at the level of large industrial companies.
The combination of reasonable price, ease of use, and professional capabilities makes Balanset-1A an vital tool for modern technical maintenance. Investment in this device is an investment in equipment stability, reduced operating costs, and improved competitiveness of your enterprise.
